Features
Frequency Range:300~60000MHz
Typical 0.05dB Chebyshev response
Sections 2~10
% 3dB bandwidth 0.3%-5% or wider
Maximum VSWR 1.2:1 (Typ 1.5:1)
2.5Fc parasitic passband (4Fc or more)
Optimized structures for custom requirement

Specification
Freq(MHz) 300-60000
BW/Fc×100% 0.3-5%
VSWR ≤1.3:1
Power Handling *
Impedance 50 Ω
Sections 2-10
Operating Temperature -55～+85℃

Notes：* General power handling is 5W, optimized
design can reach 300W or better.
