Features
Center Frequency 1500MHz~18000MHz
Typical 0.05dB Chebyshev response Quasi-elliptical
response and linearphase design available
Flexiable structure design
Dielectric temperature compensationdesign perfect
temperature stability
Parasitic passband lower to 1.15×Fc
Custom outline available

Specification
Series HD
Freq(GHz) 1000-12000
BW/Fc×100% 0.1%~1%
VSWR ≤1.3:1
Power Handling *
Impedance 50 Ω
Sections 2-8
Operating Temperature -55~+85℃

Note：* General power handling is 5W. Optimizeddesign can reach 50W.
