Features
Center frequency range: 2~500MHz
Response: Chebyshev, Butterworth and
Bessel response all available for requirements
Balanced input/output
Good balanced phase and amplitude performance
Small size, high reliability
Package: DIP or Microstrip Pins

Specification
Frequency (Fc) 2~500MHz
%3dB Bandwidth 8~20
Number of Sections 2~6
Impendance1） 10Ω
Maximum VSWR 1.5:1
Average Power(CW) 1W
Operating Temperature -55~+85℃

Note:
1)The impedance is the balanced input one for the filter.
2)High power handling products can be customized as required.
