Cavity Filter - DG Series Multiplexer
| Part No. | Frequency Range(Hz) | Passband Loss(dB) | Passband Standing Wave | Out Of Band Suppression | Volume (mm3) |
| BKLDG-240-310M | 240~310M | 1 | 1.5:1 | >45dB@310MHz | 196x52x38 |
| BKLDG-340-410M | 340~410M | 1 | 1.5:1 | >45dB@340MHz | 196x52x38 |
| BKLDG-610-670M | 610~670M | 1 | 1.5:1 | >65dB@670MHz | 160x66x41 |
| BKLDG-710-770M | 710~770M | 1 | 1.5:1 | >65dB@710MHz | 160x66x41 |
| BKLDG-5000-5100M | 5000~5100M | 1 | 1.5:1 | >60dB@5100MHz | 127x32x20 |
| BKLDG-5200-5300M | 5200~5300M | 1 | 1.5:1 | >60dB@5200MHz | 127x32x20 |
| BKLDG-1.25-1.29G | 1.25~1.29G | 0.6 | 1.5:1 | ≤90dB(between each channel) | 120x120x80 |
| BKLDG-1.5-1.69G | 1.5~1.69G | 0.6 | 1.5:1 | ≤90dB(between each channel) | 120x120x80 |
| BKLDG-2.1-2.2G | 2.1~2.2G | 0.6 | 1.5:1 | ≤90dB(between each channel) | 120x120x80 |
| BKLDG-2.48-2.5G | 2.48~2.5G | 0.6 | 1.5:1 | ≤90dB(between each channel) | 120x120x80 |
