Rod resistors are a cylindrical type resistor that are

used in both RF and microwave applications.

Power: up to 75 Watts

Frequency(max) up to 67GHZ

Standard Resistance: 50 Ohm (10 ohms up to 500 ohms)

Resistance Tolerance: ±1%、±2%、±5%(default)

Temperature Coefficient: ≤±300PPM/°C

Temperature Range : -55°C~125°C

Default Substrate Material: Alumina, Beryllium Oxide,

or Aluminum Nitride

RoHS compliant

Standard:Q/20275660-7.2-2005
