High Power Mechanically Tuned Filters

Product Features

• High Power Handling: Specifically designed to process high levels of RF power, capable of withstanding Continuous Wave (CW) and pulsed power, making them suitable for high-power transmit systems.
• Mechanically Tunable Frequency: Achieves precise tuning of the center frequency over a certain range by mechanically adjusting the dimensions or coupling of the resonant cavities (typically via screws or knobs).
• High Q-factor, Low Insertion Loss: Combining cavity or waveguide structures, these filters provide a very high Q-factor, ensuring extremely low in-band insertion loss and maximizing system efficiency.
• Steep Out-of-Band Rejection: Possesses excellent out-of-band rejection capabilities, effectively filtering out unwanted frequency components and offering high selectivity.
• Excellent In-Band Flatness: Maintains good flatness of the signal response within the passband, ensuring distortion-free signal transmission.
• High Reliability: Utilizes robust mechanical structures and materials, ensuring long-term stable and reliable operation in harsh environments.
• Good Frequency Stability: Once tuned, the mechanical locking mechanism and stable cavity design provide excellent frequency stability.
• Highly Customizable: Filter parameters (such as tuning range, bandwidth, order, power handling capacity, connector type, etc.) can be flexibly designed and customized according to specific application requirements.

Applications

• High-Power Radar Systems: Used in radar transmitters and receivers that require changing operating frequencies based on mission, for precise frequency selection and anti-jamming.
• Electronic Warfare and Reconnaissance: In wideband frequency-hopping or multi-band jamming transmitters and receivers, used for dynamic selection of operating frequencies to counter threats or conduct spectrum reconnaissance.
• Communication Systems: Employed in radio stations, repeaters, or transmitters that require flexible adjustment of operating frequencies to adapt to different communication channels or avoid interference.
• Satellite Communication Ground Stations: Used for high-power signal filtering in ground stations that need to switch between different satellite bands or adjust links.
• High-Power Test and Measurement: In RF/microwave laboratories, for flexible filtering when testing high-power tunable signal sources, amplifiers, and components.
• Particle Accelerators: Used for precisely adjusting the resonant frequency of high-power RF cavities.
• Broadcast & TV Transmitters: In certain broadcast equipment requiring flexible adjustment of transmit frequencies.
• R&D Prototyping: Serves as a versatile tunable filtering tool during the development of new RF systems.
