SMT Isolators (Surface Mount Technology Isolators)

Product Features

• Unidirectional Transmission: Allows RF energy to transmit in one direction while absorbing energy traveling in the reverse direction.
• Small and Compact: Utilizes Surface Mount Technology, resulting in a very small size, easy integration into high-density circuit boards, and space-saving.
• High Isolation: Provides excellent port-to-port isolation, effectively protecting the signal source from load reflections, even in a compact package.
• Low Insertion Loss: Ensures minimal energy loss during forward transmission to maintain high efficiency.
• Excellent VSWR: Features good impedance matching characteristics, reducing signal reflections.
• Easy for Automated Production: The surface mount package is highly suitable for automated reflow soldering processes, improving production efficiency and consistency.
• High Reliability: Employs mature manufacturing processes and materials to ensure long-term stable and reliable operation.
• Wide Frequency Range: Applicable to various applications from low frequencies to millimeter-wave.

Applications

• Wireless Communication Systems: Widely used in cellular base stations (including 5G), small cells, repeaters, and RF front-end modules to protect power amplifiers and transceivers.
• Radar Systems: Protects sensitive transmit or receive circuits in miniaturized radar and phased array radar modules.
• Aerospace and Defense: Used in airborne, satellite-borne, and military equipment, meeting strict requirements for size, weight, and performance.
• Internet of Things (IoT) Devices: Employed in IoT modules requiring high integration, low power consumption, and stable RF performance.
• Test and Measurement Equipment: Used in test links to isolate components, ensuring the accuracy of test results.
• Microwave RF Modules: Serves as a critical passive component in various complex RF modules.
