Broadband Isolators

Product Features

• Wide Frequency Range: Capable of providing stable performance over a very broad spectrum, covering multiple communication and radar bands.
• Unidirectional Transmission: Ensures RF energy transmits in a specific direction while effectively absorbing reverse-traveling reflected energy.
• High Isolation: Offers excellent isolation performance across the entire operating bandwidth, effectively protecting the signal source from reflections and interference caused by load mismatches.
• Low Insertion Loss: Ensures minimal energy loss of the signal during forward transmission, maintaining high efficiency and signal integrity.
• Excellent VSWR: Maintains a low Voltage Standing Wave Ratio across the entire broadband, ensuring good impedance matching.
• High Power Handling: Capable of handling signals at various power levels, from low-power test applications to high-power transmission systems.
• Temperature Stability: Maintains consistent performance over a wide operating temperature range.
• Various Package Types: Available in multiple package forms such as Coaxial, Drop-in, and SMT, to adapt to different integration needs.

Applications

• General RF/Microwave Systems: Serves as a standard component for protecting sensitive devices (e.g., power amplifiers, oscillators, signal sources) from damage due to reflected power.
• Test and Measurement Equipment: Used in test links to isolate the signal source from the Device Under Test (DUT), ensuring the accuracy of measurement results by preventing external reflections.
• Broadband Communication Systems: Utilized in multi-band base stations, repeaters, and front-end modules to manage and protect signals operating across different frequency bands.
• Multi-function Radar Systems: Employed in radar applications requiring broad frequency coverage for signal routing and protecting T/R modules.
• Electronic Warfare and Reconnaissance: Used in broadband receivers and transmitters for signal protection and isolation to enhance system robustness.
• Satellite Communications: Applied in broadband satellite links (including ground stations and on-board equipment) for signal isolation and path management.
• Laboratory and R&D: Serves as a general-purpose tool during the R&D phase for building and testing various RF/microwave prototype systems.

Product Selection Table
